MB Fit24™ cfDNA Kit


Pre-scripted solution for the purification of cfDNA from up to 4 mL plasma samples

Features and Benefits

  • Ease-of-use – Automation-ready cartridges pre-filled with reagents
  • Convenience – No reagent preparation and buffer dispensing
  • High-quality purification – Up to 4mL samples lysed offline eluted in as little as 50 μL

Learn more about the MagBinder® Fit24

SKU#: B3298-10-48PF (48 Cartridges for use with the MagBinder® Fit24)

CE-IVD Kits coming soon!

Unlock the power of precision with the MB Fit24™ cfDNA Kit, your go-to solution for fast, dependable isolation of circulating DNA. Designed for use with the MagBinder® Fit24 Nucleic Acid Purification System, this kit revolutionizes your workflow, allowing for the extraction of circulating DNA from up to 4 mL plasma/serum samples.

Automation-Ready Efficiency

Experience the simplicity of the MB Fit24™ cfDNA Kit. This kit is automation-ready, featuring reagent cartridges pre-filled with industry-leading Mag-Bind® reagents along with validated scripts for the MagBinder® Fit24 instrument. Enjoy fast and consistent results, with a semi-automated extraction workflow capable of processing up to 24 x 4mL samples in less than 55 minutes.

Enhanced Ease-of-use

Say goodbye to time-consuming steps. The MB Fit24™ cfDNA Kit streamlines your process by eliminating reagent preparation and buffer dispensing. Samples are lysed offline, and the lysate is transferred to the reagent well containing the binding buffer. This unique binding buffer allows for the processing of large sample volumes, up to 4 mL, in a semi-automated format without the need for sample splitting.

Reproducible, High-Quality Output

Benefit from the enhanced properties of Mag-Bind® Particles CH magnetic beads, ensuring fast and efficient separation during steps involving large volumes. The high-binding capacity reduces the volume of magnetic particles required, resulting in a decreased elution volume. Obtain DNA from up to 4 mL plasma or serum eluted in as little as 50 μL, with the kit optimized to extract smaller DNA fragments (150-400 bp) while minimizing the binding of larger fragments.

Transform your DNA extraction experience with the MB Fit24™ cfDNA Kit. Elevate efficiency, accuracy, and convenience in your laboratory. Contact your Omega Bio-tek representative to embark on a journey of seamless cfDNA isolation.

Starting amount
Up to 4 mL plasma/serum
Elution Volume
50-100 uL
Magnetic Beads
Processing Mode
Estimated offline Processing
40 minutes
Online Processing Time
53 minutes
Downstream applications: NGS, qPCR

TapeStation Analysis Shows Well-Defined cfDNA Peaks

Figure 1. TapeStation Analysis of cfDNA extracted from 4 mL of plasma from Lot L show well-defined cfDNA peaks, with additional multimers above.

Average Ct Values Illustrate Absence of Inhibitors

Figure 2. qPCR analysis results in a ΔCt within the expected range of 1-1.5 for the cfDNA extracted using the MB Fit24 cfDNA Kit, illustrating reduced inhibition.

Product Information

Protocol ManualProduct ManualEnglish
MagBinder® Fit24 – Automated, high-volume DNA & RNA purification BrochureProduct LiteratureEnglish
cfDNA Extraction Simplified: An Automated Workflow on Omega Bio-tek’s MagBinder Fit24 PlatformApplication NoteEnglish
Using ddPCR to Detect Rare Variant Alleles in cfDNA Samples on the MagBinder Fit24 PlatformApplication NoteEnglish
